Quick Details

  • Condition: New
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Shengda
  • Model Number: SHD1000
  • Input Voltage: 380V,50HZ
  • Power: 24KW
  • Usage: plastic pipes welding
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • machine color: red or blue
  • guarantee: 12 o 14 months
  • pipe size: 630,710,800,900,1000 mm
  • applicaiton: PE, PP, PVDF

Packaging & Delivery

Packaging Details plywood case

SHD1000 HDPE pipe welding machine( crane included)

PE pipe welder, plastic pipe butt fusion welding machine







Application and Features:
♦ Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF in a ditch in worksite or workshop.
Consists of basic frame, hydraulic unit, planing tool, separate heating plate, support for planing tool & heating plate, crane with hoist and optional parts.
 Removable PTFE coated heating plate with high accurate temperature control system.
 Electric planning tool with safety limit switch enables to start it only when it is locked in operation position.
♦  Made of lightweight and high strength material.
♦  Low starting pressure and high reliable seal structure.
Changeable welding position brings more convenience while welding various fittings.
Separate two-channel timer records times in soaking and cooling phases.
High-accurate and shockproof pressure meter indicates clearer readings.
Labor saving and high efficient crane is available to lift planing tool and heating plate .



The main parameters:



Model

SHD1000

Pipe size(mm)

630,710,800,900,1000

Heating plate Max. Temp.

270°C

Temp. deviation in surface(170~250°C)

<±7°C

Pressure adjustable ranges

0-16Mpa

Working voltage

380V,50Hz

Heating plate power

17.5KW

Planing tool Power

3KW

Hydraulic unit power

3KW

Crane power

0.5kw

Total power

24KW



Optinoal parts:























cking list:





Item

Packing size (mm)

N.W (kg)

G.W (kg)

Remark

1

2550×1900×2100

1330

1410

Basic frame

( include liners 630~900mm)

2

860×500×650

60

75

Hydraulic unit

3

1650×1150×2200

760

820

Heater, trimmer, support, attachments and spare parts

4

3200x740x780

180

215

Crane

5

350x500x570

70

80

Electric hoist

Total

16.59CBM

2400

2600





Company profile:

Our company WUXI SHENGDA PLASTIC PIPES WELDING MACHINE CO., LTD  is the leader  manufacturer of butt fusion equipment in China.  We occupy the 70% domestic market and export to more than 45 countries. We specialize in producing a complete range of international standard butt fusion equipment includingfield welding machine, workshop fitting machine, pipe saw, all the optional parts and tools required under the ISO9001 system and approved to CE standards by SGS.




Contact:
